Overview

This document explains how to integrate Google Workspace with the RCDevs OpenOTP Identity Provider (IdP) using SAML 2.0.
The integration enables Single Sign-On (SSO) for Google Workspace users, allowing them to authenticate securely through the OpenOTP Authentication Server.

IdP Configuration on Google Workspace

Access the Admin Console

Log in to your Google Workspace Admin Console:
https://admin.google.com/

Navigate to:
Security → Authentication → SSO with third-party IdP

Click Add SAML profile and configure as follows:

Parameter Value
SSO profile name OpenOTP
Autofill email Send the email address in the URL as the login_hint parameter to pre-fill the username field on the Identity Provider's sign-in page.
IdP entity ID https://sso.rcdevsdocs.com/openid/
Sign-in page URL https://sso.rcdevsdocs.com/openid/index.php
Sign-out page URL https://sso.rcdevsdocs.com/openid/index.php
Change password URL https://sso.rcdevsdocs.com/pwreset/index.php
Verification certificate Download from WebADM → Applications → Single Sign-On → Configure → Server Certificate or from your SAML metedata URL

You can retrieve your IdP metadata by visiting your SAML metadata URL similar to:

https://sso.rcdevsdocs.com/ws/saml

This URL provides XML output similar to:

<EntityDescriptor xmlns="urn:oasis:names:tc:SAML:2.0:metadata" entityID="https://sso.rcdevsdocs.com">
<IDPSSODescriptor protocolSupportEnumeration="urn:oasis:names:tc:SAML:2.0:protocol">
<KeyDescriptor use="signing">
<KeyInfo xmlns="http://www.w3.org/2000/09/xmldsig#">
<X509Data>
<X509Certificate>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</X509Certificate>
<!--  Cert Fingerprint (SHA1): 32774463a2e892150f46852b3fdcac7f5be924dc  -->
<!--  Cert Fingerprint (SHA256): e0bd10584f5c3a554e279b9241619e8fdf9c3bfbe95c90da939f0342546e52ac  -->
<!--  Cert Fingerprint (MD5): 639ed5b4241047c8382f897fc459a714  -->
</X509Data>
</KeyInfo>
</KeyDescriptor>
<SingleLogoutService Binding="urn:oasis:names:tc:SAML:2.0:bindings:HTTP-Redirect" Location="https://sso.rcdevsdocs.com/openid/index.php"/>
<SingleLogoutService Binding="urn:oasis:names:tc:SAML:2.0:bindings:HTTP-POST" Location="https://sso.rcdevsdocs.com/openid/index.php"/>
<SingleSignOnService Binding="urn:oasis:names:tc:SAML:2.0:bindings:HTTP-Redirect" Location="https://sso.rcdevsdocs.com/openid/index.php"/>
<SingleSignOnService Binding="urn:oasis:names:tc:SAML:2.0:bindings:HTTP-POST" Location="https://sso.rcdevsdocs.com/openid/index.php"/>
</IDPSSODescriptor>
</EntityDescriptor>

Click Save.

Configure Service Provider (SP) Details

Select your newly created SSO profile and click Edit SP Details.

In the SP Certificate section, click Generate Certificate.
Copy the Entity ID value and the ACS URL as you will need it in the next section then Save.

Google Workspace configuration on the IdP

Client Policy Configuration

Let's create a Client Policy for Google Workspace.
Login on WebADM Administrator portal, click on Admin tab, click on Client Policies and then Add Client button. Name your client policy and optionally provide a description.

Click on the Proceed and Create Object buttons.

You are now entering the policy configurator. Configure the Default Domain, a Friendly Name (optional), and set the Client Name Aliases with the Entity ID retrieved in the previous section.

Parameter Value
Friendly Name Google Workspace
Client Name Aliases Use the Entity ID from the Google SSO profile

Scroll down in the policy to locate the Default Application Settings section, then click on the checkbox Application Settings and then click Edit. In the Applications box, select OpenID & SAML Provider and configure the following parameters:

Parameter Value
Name Identifier Email
Peer Certificate Use the SP certificate from the Google profile
Encrypt SAML Response Yes
Assertion Consumer Service (ACS) URL Use the ACS URL from the Google profile

Once your SAML settings are configured, navigate to MFA Authentication Server under the Applications section and define the authentication policies you want to apply for Google Workspace logins.

Verification

After completing both configurations:

  1. Log out of your current Google Workspace session.
  2. Go to https://mail.google.com/ or any other Google service.
  3. Enter your Google account username. You will then be redirected to the RCDevs Identity Provider login page.
  4. Authenticate through the Identity Provider. Upon successful authentication, you will be redirected back to Google Workspace.
